Planetary Mixer
Product Description:
The stirring paddle in the kettle rotates while revolution, which make material flow around, so it can realize mixing (compounding) effect in short time.
Product Characteristics:
- There are various blades as frame, paddle and twist of dough frame for low speed blade can be chosen.
- Vacuum design ensure material work under sealed environment.
- Heating means of kettle can be electrical heating, steam heating, hot water or oil circulation heating, intelligent temperature director can control temperature precisely.
Technical Specification
| Parameter/Type | FXJ-02L | FXJ-05L | FXJ-100L | FXJ-200L | FXJ-500L | FXJ-1000L | |
|---|---|---|---|---|---|---|---|
| Bowlsize (Dia.×Dep) |
φ180/120×150 |
φ240/288×180 |
φ600×460/500 |
φ720/750×650 |
φ1000×380 |
φ1250×1000 |
|
| Capacity(L) |
Full volume |
3/3.8 |
8/11.7 |
130/140 |
265/287 |
650 |
1227 |
|
Working volume |
2 |
5 |
100 |
200 |
500 |
1000 |
|
| Power (Kw) |
0.37~0.75 |
0.55~1.5 |
4~11 |
7.5~15 |
15~37 |
30~55 |
|
| Agitating speed on own axis (rpm) |
0-100 |
0-100 |
0-100 |
0-80 |
0-60 |
0-50 |
|
| Orbital/scraping speed (rpm) |
0-60 |
0-60 |
0-60 |
0-50 |
0-40 |
0-30 |
|
| Raising/lowering stroke (mm) |
220 |
270 |
560 |
750 |
930 |
1100 |
|
| Vacuum (Mpa) |
-0.098～-0.08 |
-0.098～-0.08 |
|||||
Double planetary mixer
Product Description:
There are various blades as frame, paddle and twist of dough frame for low speed blade can be chosen.
Product Characteristics:
- The stirring paddle in the kettle rotates while revolution, which make material flow around, so it can realize mixing (compounding) effect in short time.
- The additional one or two high-speed disperser in the kettle rotate while revolution, which make the material be strongly cut and mixed, the effect is severalfold than ordinary mixer.
- Vacuum design ensure material work under sealed environment.
- Heating means of kettle can be electrical heating, steam heating, hot water or oil circulation heating, intelligent temperature director can control temperature precisely.
Technical Specification
| Parameter/Type | FXDJ-02L | FXDJ-05L | FXDJ-100L | FXJ-200L | FXJ-500L | FXJ-1000L | |
|---|---|---|---|---|---|---|---|
| Bowlsize (Dia.×Dep) |
φ180×120/150 |
φ240/288×180 |
φ600×460/500 |
φ720/750×650 |
φ1000×380 |
φ1250×1000 |
|
| Capacity(L) | Full volume |
3/3.8 |
8/11.7 |
130/140 |
265/287 |
650 |
1227 |
| Working volume |
2 |
5 |
100 |
200 |
500 |
1000 |
|
| power for dispers (Kw) |
0.37~0.75 |
0.75~2.2 |
4.0~11 |
11~22 |
22~45 |
37~75 |
|
| didpersing speed on own axis (rpm) |
0-3000 |
0-3000 |
0-3000 |
0-2500 |
0-1500 |
0-960 |
|
| Power (Kw) |
0.37/0.75 |
0.55/1.5 |
4.0/11 |
5.5/18.5 |
15/37 |
22/55 |
|
| Agitating speed on own axis (rpm) |
0-100 |
0-100 |
0-100 |
0-80 |
0-60 |
0-50 |
|
| Orbital/scraping speed (rpm) |
0-60 |
0-60 |
0-60 |
0-50 |
0-40 |
0-30 |
|
| Vacuum (Mpa) |
-0.098～-0.08 |
-0.098～-0.08 |
|||||
